Extech 407780A Integrating Sound Level Meter with USB

This instrument offers a 30-130 dB measurement range (with five selectable ranges) and 0.1 dB resolution, meeting Type 2 accuracy standards (±1.5 dB) under the relevant IEC 61672-1 / 60651/60804 and ANSI S1.4 specifications.

The 4-digit multifunction LCD features a bar-graph and digital read-out. Users can switch between measurement modes for SPL (sound pressure level), SPL Min/Max, SEL, and Leq, and choose time-weightings (Impulse, Fast, Slow) and frequency-weightings (A, C).

For data-logging the 407780A stores up to 32,000 records via its internal memory and can transfer data to a PC via the USB interface with bundled Windows-compatible software.
Analog AC/DC outputs and alarm output features enable external chart recorders or trigger systems. A tripod mount and field-friendly form-factor (approx. 265 × 72 × 21 mm, ~310 g) allow for stable monitoring setups.
The unit is supplied with windscreen, USB cable, software, battery and hard case; powered by four AA batteries (approx. 20-24 h battery life) or optionally via AC adapter.

Features

• Measurement range: 30 dB to 130 dB across five selectable ranges.

• Type 2 accuracy (±1.5 dB at 94 dB/1 kHz) complying with IEC/ANSI standards.

• Display modes: SPL, SPL Min/Max, SEL, Leq; also Peak-Hold and percentile levels (L05, L10, L50, L90, L95) supported.

• Frequency weighting: A and C; Time weighting: Impulse (~35 ms), Fast (~125 ms), Slow (~1 s).

• Built-in datalogger: up to 32,000 records, real-time clock stamps, USB interface with PC software.

• Analog AC/DC output and alarm output for external monitoring/triggering.

• High linearity across a 100 dB span for accurate readings throughout the range.

• Tripod mount capability for long-term monitoring or fixed installations.

• Supply: Four AA batteries, optional AC adapter; compact and portable design (~310 g).

Includes

• Windscreen
• Adjustment screwdriver
• USB cable
• Windows compatible software
• Battery
• One year warranty
• Case
