Fluke 566-2 Thermal Gun Infrared & Contact Thermometer

The Fluke 566-2 is an advanced two-in-one infrared and contact thermometer, perfect for professionals working in industrial, electrical, HVAC, and mechanical environments. This versatile tool allows for both non-contact temperature measurements using infrared technology and contact temperature measurements through K-type thermocouples, making it a highly flexible solution for a wide range of applications.

With a 30:1 distance-to-spot ratio, the Fluke 566-2 can measure smaller objects from a greater distance, making it safer and easier to take temperature readings without having to physically access the equipment. The device features a broad temperature range of -40°C to 650°C (-40°F to 1202°F) for infrared measurements and -270°C to 1372°C (-454°F to 2501°F) for K-type thermocouple contact measurements, ensuring it can handle even the most demanding industrial tasks.

The Fluke 566-2 is designed for ease of use with an intuitive dot-matrix graphical display and soft-key menus, allowing users to quickly adjust settings like emissivity and access advanced functions. Audible and visual alarms notify users when measurements fall outside pre-set limits, and the device can store up to 20 data points with a date/time stamp for easy tracking and documentation. The thermometer’s adjustable emissivity allows for accurate temperature readings across various materials, ensuring precise diagnostics.

Its rugged, ergonomic design ensures that the Fluke 566-2 can withstand harsh working environments, making it ideal for those who require durability and reliability in tough conditions. Whether you are troubleshooting electrical panels, HVAC systems, or mechanical equipment, the Fluke 566-2 provides the flexibility and accuracy you need for reliable temperature diagnostics.

Features

• Dual Functionality: Measures temperature via both infrared (non-contact) and K-type thermocouples (contact).
• Wide Temperature Range: Infrared range from -40°C to 650°C (-40°F to 1202°F) and K-type thermocouple range from -270°C to 1372°C (-454°F to 2501°F).
• 30:1 Distance-to-Spot Ratio: Enables measuring smaller objects from a safer and greater distance.
• Adjustable Emissivity: Provides more accurate measurements across different materials, with a built-in material table.
• Data Logging: Stores up to 20 data points with a date/time stamp for later retrieval.
• Audible & Visual Alarms: Alerts users when temperature readings exceed set high or low limits.
• Rugged Design: Built to endure tough industrial, electrical, and mechanical environments.
• Dot-Matrix Display: Clear graphical display with soft-key buttons for easy navigation of advanced features.
• Battery Life: Up to 12 hours of continuous use with laser and backlight on, 100 hours with both off.
• Multiple Display Functions: Includes MIN, MAX, Average, and Difference (DIF) for quick problem-solving.

Includes

• K-type thermocouple bead probe
• Durable hard case
• 2 AA batteries
• Quick start guide in 6 languages
• Two-year warranty
