Fluke 700LTP-1 Low-pressure Test Pump
The Fluke 700LTP-1 is a lightweight, hand-operated low-pressure pump designed for generating vacuum up to –12.7 psi (–0.87 bar) or pressure up to 100 psi (6.9 bar). With quick-fit connectors, an adjustable relief valve, and easy-to-clean design, it’s ideal for precise low-pressure calibration applications.
Description
The Fluke 700LTP-1 Low-pressure Test Pump is engineered for accurate, portable, and easy-to-use pressure testing in low-pressure environments. This compact handheld device generates either vacuum (down to –12.7 psi / –0.87 bar) or pressure (up to 100 psi / 6.9 bar), making it highly versatile for field and bench calibration tasks. Equipped with two quick-fit connectors, one connects seamlessly to Fluke 700 series pressure modules and 717 pressure calibrators, while the other connects to the unit under test.
Designed with user efficiency in mind, the 700LTP-1 features an adjustable pressure relief valve with slow-bleed capability, allowing precise and controlled pressure release. Its slim and lightweight build, weighing only 226 g, ensures it is easy to carry and operate in tight spaces. Built from durable materials such as aluminum, stainless steel, silicon, neoprene, and Buna-N, the pump delivers long-term reliability and performance. The test hoses are terminated with 1/8-NPT female fittings, which can be adapted to BSP/ISO standards, increasing flexibility for different setups. With its one-year warranty and robust design, the 700LTP-1 is a practical tool for technicians requiring dependable low-pressure testing.
Features
- Generates vacuum up to –12.7 psi (–0.87 bar) or pressure up to 100 psi (6.9 bar)
- Hand-operated, portable, and slim design for field use
- Quick-fit connectors for easy connection to Fluke 700 series pressure modules and 717 calibrators
- Adjustable pressure relief valve with controlled slow-bleed capability
- Easy-to-clean construction without disassembly
- Lightweight build: only 226 g (0.5 lbs)
- Durable exposed materials: aluminum, stainless steel, silicon, neoprene, and Buna-N
- Compact dimensions: 150 × 100 × 32 mm (5.9 × 4 × 1.25 in)
- Compatible with BSP/ISO adapters via 1/8-NPT female fittings
- Backed by a one-year warranty
Includes
- (2) adapters to convert the reference and UUT port hose fitting to 1/4″ BSP female
- One seal kit
- Instruction sheet in English
