Fluke 718 Pressure Calibrator
The Fluke 718 Pressure Calibrator is a compact, lightweight tool with a built-in pump for pressure sourcing up to 300 psi. It combines pressure generation, mA measurement, and switch testing in one handheld device, delivering 0.025% accuracy and field-serviceable reliability for versatile pressure calibration tasks.
Description
The Fluke 718 Pressure Calibrator is an all-in-one solution for calibrating transmitters, gauges, and pressure switches. Featuring an integrated pressure pump capable of sourcing up to 300 psi, it eliminates the need for separate hand pumps and bulky equipment. Despite its robust performance, the 718 is about one-third the size of comparable calibrators and weighs only one kilogram, making it an ideal choice for field technicians who need portability and efficiency.
Its easy-to-clean, field-serviceable pump design minimizes downtime by reducing damage from contaminants and allowing quick maintenance without disassembly. With 0.025% pressure accuracy and 0.015% mA measurement accuracy, the Fluke 718 provides confidence in high-precision calibration tasks. The built-in switch test makes calibrating pressure switches simple, while the error % calculation function allows for instant pass/fail decisions in the field.
Available in 1, 30, 100, and 300 psi models, the 718 also supports extended pressure ranges through compatibility with Fluke 750P Pressure Modules, covering up to 10,000 psi. Additional features like min/max/hold functions, a 24 V loop power supply, and simultaneous pressure/mA display make the 718 a reliable, field-ready calibration tool. Backed by a three-year warranty, it delivers the accuracy, durability, and convenience that process professionals demand.
Features
- Built-in pump generates and sources pressure up to 300 psi for fast calibration.
- Compact and lightweight design—about one-third the size of similar tools, only 1 kg.
- 0.025% pressure accuracy and 0.015% mA accuracy ensure precise calibrations.
- Integrated pressure switch test simplifies switch calibration and validation.
- Error % calculation function enables quick pass/fail field decisions.
- Easy-to-clean, field-serviceable pump reduces downtime and extends tool life.
- Available models: 1, 30, 100, and 300 psi ranges.
- Extended range capability when paired with Fluke 750P Pressure Modules (up to 10,000 psi).
- 24 V loop supply to power transmitters during testing.
- Min/Max/Hold and Damp functions for capturing and analyzing dynamic measurements.
Includes
- Fluke 718 1G
Fluke 718 1G Pressure Calibrator -1 to 1 psi, (-68.9 mbar to 68.9 mbar, -6.89 to 6.89 kPa)
Protective Yellow Holster with test lead storage
Instructions Sheet (14 languages)
Test Leads and Alligator Clip
Two 9V alkaline batteries
NIST – Traceable calibration report and data - Fluke 718 30G
Fluke 718 30G Pressure Calibrator -12 psi to 30 psi, (-850 mbar to 2 bar, -85 to 206.84 kPa)
Protective Yellow Holster with test lead storage
Instructions Sheet (14 languages)
Test Leads and Alligator Clip
Two 9V alkaline batteries
NIST – Traceable calibration report and data - Fluke 718 100G
Fluke 718 100G Pressure Calibrator -12 psi to 100 psi, (-850 mbar to 7 bar, -85 to 689.48 kPa)
Protective Yellow Holster with test lead storage
Instructions Sheet (14 languages)
Test Leads and Alligator Clip
Two 9V alkaline batteries
NIST – Traceable calibration report and data - Fluke 718 300G
Fluke 718 300G Pressure Calibrator -12 psi to 300 psi, (-850 mbar to 20 bar, -85 to 2068.42 kPa )
Protective Yellow Holster with test lead storage
Instructions Sheet (14 languages)
Test Leads and Alligator Clip
Two 9V alkaline batteries
NIST – Traceable calibration report and data
