Fluke 753 Documenting Process Calibrator

The Fluke 753 Documenting Process Calibrator is an advanced, all-in-one solution for process calibration and troubleshooting. Designed for maximum efficiency, it combines the functionality of multiple instruments into a single, portable tool. It can measure, source, and simulate volts, mA, ohms, RTDs, thermocouples, frequency, and pressure, making it suitable for sensors, transmitters, switches, and other process instruments.

One of its key advantages is simultaneous source and measure capabilities, which streamline testing and reduce the need for extra tools. With built-in support for over 50 Fluke 700Pxx pressure modules, it adapts to a wide range of pressure calibration tasks. The 753 also automates as-found/as-left calibration procedures, ensuring accuracy, consistency, and compliance with quality programs and regulatory requirements such as ISO 9000, FDA, EPA, and OSHA.

Data handling is another strength of the Fluke 753. It features a USB interface for two-way communication with calibration management software, including Fluke DPCTrack2™, enabling seamless paperless workflow, archiving, and analysis. Technicians can download calibration instructions, execute procedures in the field, and then upload results for reporting and audit trails. Its large dual display, multilingual user interface, and intuitive controls make it easy to use in demanding environments.

Built for durability, the Fluke 753 features a rugged, handheld design, IP52-rated protection, and a rechargeable Li-ion battery for up to 10 hours of continuous operation. It supports flexible features such as autostep, square root DP flow testing, custom units, programmable delays, switch testing, and user-defined values, ensuring it can handle complex calibration scenarios. Backed by a three-year warranty, this calibrator is a dependable choice for professionals who need accuracy, speed, and comprehensive documentation in one device.

Features

• Multifunction calibrator: measures, sources, and simulates volts, mA, ohms, RTDs, thermocouples, frequency, and pressure
• Automated calibration procedures with as-found/as-left documentation for regulatory compliance
• Simultaneous source and measure capability for faster testing and troubleshooting
• Compatible with over 50 Fluke 700Pxx Pressure Modules for versatile pressure calibration
• USB interface for seamless integration with Fluke DPCTrack2™ and other management software
• Stores up to one week of calibration procedures and results
• Flexible functions: autostep, custom units, user-entered values, and square root DP flow testing
• Bright dual display with multilingual interface for clarity and ease of use
• Rugged, IP52-rated design with rechargeable Li-ion battery (10-hour runtime)
• Backed by a three-year warranty for reliability and long-term use

Includes

• Fluke 753 Documenting Process Calibrator
• BC7240 battery charger
• Li-on BP7240 battery pack
• NIST-traceable calibration report and data
• (3 sets) TP220 test probes
• (3 sets) “Extended tooth” alligator clips
• (3 sets) Stackable test leads
• (2 sets) AC280 hook clips
• C799 Soft Field Case
• USB communication cable
• Quick Reference Guide
• 3-year warranty
