Fluke FEV300 EV Charging Station Test Adapter

The Fluke FEV300 EV Charging Station Test Adapter is a versatile and reliable testing solution designed for professionals who maintain and troubleshoot Mode 3 AC EV charging stations. Featuring a Type 2 connector, the FEV300 adapter simulates an electric vehicle to activate the charging cycle, allowing accurate testing of voltage, current, insulation, and fault conditions—without requiring an EV on-site.

When combined with compatible test instruments such as the Fluke 1664 FC Installation Tester or Fluke 120B ScopeMeter®, the FEV300 provides a comprehensive testing solution to ensure that charging stations comply with IEC/EN 61851-1 and IEC/HD 60364-7-722 standards.

Its intuitive design enables seamless integration with Fluke’s portfolio of measurement tools. With the PP State rotary switch, users can simulate different charging cable capabilities, while the vehicle simulation mode tests various charging states. The adapter also allows simulation of CP (Control Pilot) errors and PE (Earth Fault) errors to verify station response under fault conditions.

Equipped with three LED phase indicators, it provides a quick visual confirmation of voltage presence. By simulating an EV connection, the FEV300 eliminates the need to bring an electric vehicle on-site, making charging station testing, commissioning, and maintenance faster, safer, and more efficient.

Features

• Comprehensive EV charger testing for Mode 3 AC charging stations with Type 2 connectors.
• Simulates an electric vehicle to activate the charging cycle and perform functional tests without an EV.
• Compatible with Fluke test instruments like the Fluke 1664 FC Installation Tester and 120B ScopeMeter®.
• Supports IEC/EN 61851-1 and IEC/HD 60364-7-722 compliance for safe and accurate testing.
• Perform multiple tests including ground fault detection, insulation resistance, voltage checks, and duty cycle measurement.
• Vehicle simulation & cable simulation modes allow testing across various charging states and current capabilities.
• PE (Earth Fault) and CP (Control Pilot) error simulation ensures proper response from the charging station.
• Three LED phase indicators provide a quick visual check for voltage presence on all phases.
• Plug-and-play operation eliminates the need to bring an electric vehicle to the test site.
• Robust, portable, and easy to integrate with the complete Fluke measurement ecosystem.

Includes

• FEV300/BASIC Test Adapter
• FEV300-CON-TY2 Type 2 Plug
• Carrying case
