Hioki BT3562 Battery HiTester

The Hioki BT3562 Battery HiTESTER is engineered to provide accurate and rapid measurements of internal resistance and open-circuit voltage in battery packs and modules. It supports a wide resistance measurement range from 3 mΩ to 3000 Ω, accommodating both low-resistance coin-size cells and larger high-resistance batteries. The voltage measurement range spans from 6 V to 60 V DC, ensuring compatibility with various battery configurations. The instrument delivers high-speed measurements with a response time of 10 ms and a sampling rate of 4 ms in “Extra-FAST” mode, making it suitable for high-throughput production environments. Its enhanced current regulation circuitry ensures stable and reliable measurements across the entire range. The BT3562 is equipped with multiple interfaces, including GP-IB, RS-232C, and external I/O, facilitating seamless integration into automated testing systems. Its robust design and precise measurement capabilities make it an essential tool for battery manufacturers and researchers focusing on battery performance and quality control.

Features

• Wide Resistance Measurement Range: Measures from 3 mΩ to 3000 Ω, suitable for both low-resistance and high-resistance batteries.
• Voltage Measurement Capability: Supports voltage measurements from 6 V to 60 V DC, accommodating various battery configurations.
• High-Speed Measurements: Achieves a response time of 10 ms and a sampling rate of 4 ms in “Extra-FAST” mode for rapid testing.
• Enhanced Current Regulation: Employs advanced circuitry to maintain stable and accurate measurements across the entire range.
• Multiple Communication Interfaces: Equipped with GP-IB, RS-232C, and external I/O interfaces for easy integration into automated systems.
• High Accuracy: Provides precise measurements with a voltage accuracy of ±0.01% of reading ±3 digits.
• User-Friendly Display: Features a clear LED display with 31,000 full digits for resistance and 600,000 full digits for voltage.
• Robust Design: Built to withstand the demands of production environments, ensuring durability and reliability.
• Simultaneous Measurements: Capable of measuring internal resistance and open-circuit voltage simultaneously for efficient testing.
• Versatile Application: Ideal for testing large cells, including lithium-ion batteries used in electric vehicles and other high-voltage applications.

Includes

• Instruction manual ×1
• Power cord ×1
