SMFT-1000 Solar Tools Kit: Fluke Multifunction PV Tester and Performance Analyzer, I-V Curve Tracer

The Fluke SMFT-1000 Solar Tools Kit is a complete testing, commissioning, and performance analysis solution designed for professionals who install, maintain, and troubleshoot photovoltaic (PV) systems operating at 1000 V DC or below. Featuring a multifunction PV tester, I-V curve tracer, and integrated data management capabilities, the SMFT-1000 ensures optimal energy production while maintaining strict compliance with IEC 62446-1 standards for Category 1 and Category 2 testing.

Equipped with advanced capabilities, the SMFT-1000 performs a full sequence of PV safety tests, including open-circuit voltage (Voc), short-circuit current (Isc), insulation resistance (Rins), polarity verification, and protective earth resistance (Rpe). For high-efficiency PV modules (>19%), the tester measures operational current instead of Isc to comply with IEC standards using the Fluke i100 AC/DC Current Clamp (sold separately).

With built-in I-V curve tracing, users can instantly compare measured data with manufacturer specifications directly on the device’s color display—eliminating the need for laptops or tablets in the field. The included IRR2-BT wireless irradiance meter provides real-time irradiance and temperature data to deliver the most accurate I-V measurements possible. Even if wireless connectivity drops, the meter stores up to 17 hours of recorded data for later syncing.

Powered by Fluke TruTest™ Solar Software, the SMFT-1000 allows effortless organization, analysis, and reporting of test data. It also integrates with the Fluke TruTest™ Solar Database App, giving you access to over 120,000 PV module specifications—saving time and eliminating manual data entry during testing.

Designed for speed and accuracy, the SMFT-1000’s “Keep the Leads” system minimizes lead changes between tests, while Auto Test Mode streamlines testing sequences for faster commissioning. Whether you are testing new installations or performing ongoing inspections, the SMFT-1000 simplifies data management, ensures IEC compliance, and produces clear, professional reports for clients.

Features

• All-in-one PV testing solution for installation, commissioning, performance analysis, and troubleshooting.
• Meets IEC 62446-1 Category 1 & 2 standards for complete PV system testing and safety verification.
• Built-in I-V curve tracing instantly compares measured results against manufacturer specifications on-screen.
• Wireless irradiance meter (IRR2-BT) provides real-time irradiance and temperature data for accurate I-V measurements.
• Fluke TruTest™ Solar Software integration for seamless data management, reporting, and certification generation.
• TruTest™ Solar Database App offers access to over 120,000 PV panel specifications, eliminating manual entry.
• Auto Test Mode performs a sequence of tests—including insulation resistance, polarity, Voc, Isc, and Rpe—with a single setup.
• “Keep the Leads” system minimizes lead changes for faster, more efficient testing in the field.
• Visual pass/fail indicators and on-screen I-V curve display make instant verification easier.
• Ideal for PV professionals installing, commissioning, and maintaining systems up to 1000 V DC.

Includes

• Fluke SMFT-1000-BP Professional Tool Backpack
• SMFT-1000 Multifunction PV Analyzer
• Carry Strap
• Fuse Pack
• Adapter Cable IRDA Optical-to-USB
• Zero Adapter
• IRR2-BT Wireless Solar Irradiance Meter Pro
• 80PR-IRR External Temperature Probe
• Mounting Bracket for solar panel
• Carry Case
• i100 AC/DC Current Clamp 100 A
• TPAK Magnet Set
• TP1000 Test Probe with Remote Test Button
• TL1000 Test Lead Set
• TL1000-MC4 Test Lead Set
• TL1000/30M Test Lead on Reel
• Coupler set
