Extech 380395 High Voltage Digital Insulation Tester (110 V)

The Extech 380395 High Voltage Digital Insulation Tester is engineered to deliver precise insulation resistance measurements across a wide voltage range. With selectable test voltages of 500V, 1000V, 2500V, and 5000V, it allows for testing insulation resistance up to 60 GΩ, accommodating various electrical systems and components.

In addition to insulation resistance testing, the 380395 offers AC/DC voltage measurement capabilities up to 600V, enabling users to assess both insulation and operational voltage levels. The device features a large 6000-count LCD display with a bargraph and backlight, ensuring clear visibility of readings even in low-light conditions.

For evaluating the quality of insulation over time, the 380395 includes Polarization Index (PI) and Dielectric Absorption Ratio (DAR) measurement functions. These features are essential for assessing the aging and condition of insulation materials.

The tester also incorporates a 1 to 15-minute timer function for insulation resistance measurements, allowing users to conduct timed tests for more accurate assessments. Safety features include an auto-discharge function to safely discharge test voltage after measurements, and a voltage output warning function to alert users of any potential hazards.

Powered by eight C batteries or an included 120V AC adapter, the 380395 is designed for portability and convenience. It comes complete with test leads, a heavy-duty carrying case, and a user manual, providing all necessary tools for efficient testing.

Features

• Selectable Test Voltages: 500V, 1000V, 2500V, and 5000V for versatile insulation testing.
• High Insulation Resistance Measurement: Up to 60 GΩ to assess insulation integrity.
• AC/DC Voltage Measurement: Up to 600V with Min/Max, Peak, and Relative functions.
• Polarization Index (PI) Measurement: Evaluate insulation quality over time.
• Dielectric Absorption Ratio (DAR) Measurement: Assess insulation aging and condition.
• Timer Function: 1 to 15-minute timer for insulation resistance measurements.
• Auto-Discharge Function: Safely discharges test voltage after measurements.
• Voltage Output Warning Function: Alerts users of potential hazards.
• Large LCD Display: 6000-count display with bargraph and backlight for clear readings.

Includes

• Test leads
• Eight C batteries
• 120 V AC adaptor
• Heavy duty carrying case
• User manual
